1. Data Model

Core DB Model: Integration

Every connected channel is stored in the integrations table:

2. Platform Breakdowns

🟢 Channel A — WhatsApp Business (Evolution API)

WhatsApp integration is powered by the Evolution API (self-hosted service running Node.js + Baileys library).

Connection Flow

1. Initiation: Merchant enters their phone number in Kasi Settings.
2. Instance Creation: Backend POST /api/whatsapp/connect provisions a new WhatsApp instance via Evolution API:
   • Endpoint: POST {EVOLUTION_API_URL}/instance/create
   • Webhook Subscription: Instance registers {BASE_URL}/api/whatsapp/webhook for CONNECTION_UPDATE and MESSAGES_UPSERT events.
3. Pairing Code: Backend polls:
   GET {EVOLUTION_API_URL}/instance/connect/{instance_name}?number={phone}
   Returns an 8-character code (e.g. ABCD-1234).
4. Linkage: Merchant inputs code in WhatsApp → Linked Devices → Link with Phone Number.
5. Activation: Evolution API fires CONNECTION_UPDATE with status 'open'. Backend updates integration to connected.

Webhook Message Flow

POST /api/whatsapp/webhook

• Deduplication: Uses IdempotencyKey table + memory cache (PROCESSED_MESSAGES) to prevent duplicate processing.
• Audio Transcription: Voice notes are fetched via media API, transcribed by OpenAI Whisper or Groq Whisper, prepended with 🎤 [Voice Note]:.
• Rider Interceptor: If sender matches a vendor's saved logistics rider and confirms, the invoice is marked "In Transit" with automatic notifications.
• AI Processing: Routes text to SalesAI.process and images to SalesAI.process_image.

🔵 Channel B — Telegram Bots

Telegram integrations use dedicated bots created via @BotFather.

Connection Flow

1. Credential Entry: Merchant creates a Telegram bot, obtains the Bot Token, and inputs it in Kasi Settings.
2. Webhook Registration: Kasi registers the webhook:
   POST https://api.telegram.org/bot{token}/setWebhook?url={BASE_URL}/api/telegram/webhook/{token}
3. Database Save: Integration saved with platform 'telegram', access_token = token.

Webhook Message Flow

POST /api/telegram/webhook/<token>

• Routing: Bot token from URL → Integration.query.filter_by(access_token=token) → identifies merchant.
• Processing: Text passed to SalesAI.process.
• Dispatch: Reply via POST https://api.telegram.org/bot{token}/sendMessage.

🟣 Channel C — Instagram DM & Facebook Messenger

Meta messaging channels use a single Meta Developer App with Graph API and OAuth.

Connection Flow (OAuth)

1. Authorization Request: Frontend redirects to Facebook's OAuth URL:
   https://www.facebook.com/v21.0/dialog/oauth?client_id={APP_ID}&redirect_uri={FRONTEND_URL}/settings&scope=pages_show_list,pages_messaging,instagram_basic,instagram_manage_messages,pages_read_engagement&response_type=code&state={platform}
2. Facebook Redirect: After authorization, Facebook redirects back:
   https://usekasi.com/settings?code={auth_code}&state={instagram|facebook}
3. Code Exchange: Frontend sends code to backend:
   POST /api/meta/oauth/callback
4. Token Exchange: Backend exchanges auth code for User Access Token via Meta API.
5. Page List Query: Backend calls /me/accounts to fetch Page IDs and Page Access Tokens.
6. Account Resolution:
   • Facebook: First Page's ID → instance_name, Page Access Token → access_token.
   • Instagram: Queries each page for instagram_business_account. If found, IG Account ID → instance_name, Page Access Token → access_token.

Webhook Message Flow

POST /api/meta/webhook

• Signature Verification: Validates x-hub-signature-256 using HMAC-SHA256 with META_APP_SECRET.
• Routing: Inspects entry.messaging.recipient.id → queries Integration by instance_name.
• Image Support: CDN URLs fetched, converted to base64, passed to SalesAI.process_image.
• Response Dispatch:
  POST https://graph.facebook.com/v21.0/me/messages?access_token={page_access_token}

{
  "recipient": {"id": "sender_id"},
  "message": {"text": "AI response text here"}
}

3. Environment Variables

Configuration checklist for backend .env:

# Meta Graph API configuration
META_APP_ID=**********************
META_APP_SECRET=********************************
META_VERIFY_TOKEN=********************************

# Evolution API (WhatsApp) configuration
EVOLUTION_API_URL=http://localhost:8080
EVOLUTION_GLOBAL_API_KEY=************************

# General config
BASE_URL=https://api.usekasi.com

4. Troubleshooting

1. Meta Webhook Handshake Failing:
   Ensure META_VERIFY_TOKEN matches exactly between the Meta Developer portal and backend .env.
2. Instagram Webhooks Not Delivering:
   • Verify the Instagram account is set to Business type (Creator type has restrictions).
   • Verify the IG account is linked to the Facebook Page in Settings.
   • Confirm the PAT was granted instagram_manage_messages permission.
3. WhatsApp Pairing Code Failing:
   Check Evolution API container health: docker ps | grep evolution. Ensure the global API key matches.

1. Architecture Overview

The production VPS uses a containerized Docker network. The database container (kasi_db) runs PostgreSQL on port 5432 with no public port exposure, fully isolated inside the private Docker network (kasi-network).

Development runs on SQLite locally. Production uses PostgreSQL. Schema changes are synchronized via Alembic migration scripts.

2. Git Staging & Pushing (Local)

# Check modified files
git status

# Stage all files
git add .

# Commit with semantic message
git commit -m "feat: complete meta integration webhook"

# Push to GitHub
git push origin main

3. Deploy on VPS

# SSH into VPS
ssh root@***.***.*.*

# Navigate to backend
cd ~/kasi-backend

# Pull latest
git pull origin main

# Force-rebuild and recreate all containers
docker compose up -d --build --force-recreate

4. Log Tracing (VPS)

# Flask backend logs
docker compose logs -f kasi-backend

# Celery worker logs
docker compose logs -f celery-worker

# Evolution API logs
docker compose logs -f evolution-api

# PostgreSQL logs
docker compose logs -f kasi_db

# Filter for AI intent / errors
docker compose logs -f kasi-backend | grep -E "intent|Intent|Error"

5. Database Migrations

Migrations run inside the Flask container via docker compose exec:

# Standard upgrade
docker compose exec kasi-backend flask db upgrade

# Check current migration version
docker compose exec kasi-backend flask db current

# Stamp database to specific revision (if diverged)
docker compose exec kasi-backend flask db stamp <revision_id>

6. Direct Database Access

# Log into PostgreSQL console
docker exec -it kasi_db psql -U ******** -d ****************

Useful commands:

7. Automated Backups

Set up daily midnight PostgreSQL backups via cron:

# Edit system cron
crontab -e

# Append this line for daily midnight backup
0 0 * * * mkdir -p /root/db-backups && docker exec -t kasi_db pg_dump -U ******** **************** > /root/db-backups/backup_$(date +\%F).sql 2>&1
